36 Frame C-Face Motor

SHAFT DIAMETERS AND RABBET CONCENTRIC AND PERPENDICULAR WITHIN .002” T.I.R.
SHAFT MATERIAL - 304 STAINLESS STEEL
THE FRONT BEARING IS RETAINED TO PREVENT AXIAL MOVEMENT.
MOTORS ARE SHIPPED FROM THE FACTORY WIRED FOR LOW VOLTAGE.
INSULATION: CLASS F INSULATION / PROTECTION - OPEN

NOTES
All dimensions in inches. May vary ± ¼ inches.
Not for construction purposes unless certified.
*See motor dimensions for “C” dimension (varies depending on motor enclosure).

HORSE
POWER

ENCL.

FRAME

MTH P/N

WT.
LBS.

DIMENSIONS IN INCHES

HZ

SERVICE
FACTOR

VOLTAGE

RPM

WIRING
DIAG.

D

C

C-AH

OPN

36

FRC-5017-03-OPN

11.8

2.25

10.12

8.01

60

1.5

115/230

3450

50

1.0

115/230

2875
