D3 Motor Dimensions
 |
| SHAFT DIAMETERS AND RABBET CONCENTRIC AND PERPENDICULAR WITHIN .002” T.I.R. SHAFT MATERIAL - 304 STAINLESS STEEL FRONT BEARING IS LIPSEALED 204 OR LARGER. THE FRONT BEARING IS RETAINED TO PREVENT AXIAL MOVEMENT. MOTORS ARE SHIPPED FROM THE FACTORY WIRED FOR LOW VOLTAGE.ELECTRICAL: 2880 RPM 50 HZ 3 PHASE 190/380-415 VOLTS - 3450 RPM 60 HZ 3 PHASE 208-230/460 VOLTS - 3450 RPM 1 PHASE 60HZ 115/230 VOLTINSULATION: CLASS F INSULATION PROTECTION IP 55 PER IEC 34-1 - TEFCBEARINGS: GREASE SUITIBLE FOR OPERATION AT -40°C TO 200°C (-40°F TO 392°F) |
| NOTES All dimensions in inches. May vary ± ¼ inches. Not for construction purposes unless certified. *See motor dimensions for “C” dimension (varies depending on motor enclosure). |
