143E to 110A Series E5T Comparisons

Back to Aurora Replacements

Click and drag your mouse on the curve. Lines are automatically drawn as either horizontal or vertical. To clear the canvas, click the "Clear Lines" button below the curve.

Zoom

Clear Lines

Notes: Consult factory for operation below 4.0 GPM
*Consider 240 Series inducer if pumping at low NPSH. Add 1/2 horsepower for 240 Series models.
**Horsepower data is valid for 1.0 specific gravity fluids only. Data provided is based of performance testing with water.
