142IA to 120B Series HX4T (1750 RPM) Comparisons

Back to Aurora Replacements

Click and drag your mouse on the curve. Lines are automatically drawn as either horizontal or vertical. To clear the canvas, click the "Clear Lines" button below the curve.

Zoom

142IA to HX4T Comparison Curve at 1750 RPM

Notes: Consult factory for operation below 11 GPM
*Consider 240 Series inducer if pumping at low NPSH. Add 1/2 horsepower for 240 Series models.
**Horsepower data is valid for 1.0 specific gravity fluids only. Data provided is based of performance testing with water.
