| Ref. No. |
Part/Description |
Material |
Part Number |
| 1 |
E51B/T51B Motor Bracket |
Teflon Coated Cast Iron |
1-1804-0B-543 |
| Bronze |
1-1804-0B-206 |
| 316 Stainless |
1-1804-0B-104 |
| E51C/T51C Motor Bracket |
Teflon Coated Cast Iron |
1-5042-0C-543 |
| Bronze |
1-5042-0C-206 |
| 316 Stainless |
1-5042-0C-104 |
| E51D/T51D Motor Bracket |
Teflon Coated Cast Iron |
1-1806-0D-543 |
| Bronze |
1-1806-0D-206 |
| 316 Stainless |
1-1806-0D-104 |
| E51E/T51E Motor Bracket |
Teflon Coated Cast Iron |
1-5035-0E-543 |
| Bronze |
1-5035-0E-206 |
| 316 Stainless |
1-5035-0E-104 |
| E51G/T51G Motor Bracket |
Teflon Coated Cast Iron |
1-1808-0G-543 |
| Bronze |
1-1808-0G-206 |
| 316 Stainless |
1-1808-0G-104 |
| E51J/T51J Motor Bracket |
Teflon Coated Cast Iron |
1-1809-0J-543 |
| Bronze |
1-1809-0J-206 |
| 316 Stainless |
1-1809-0J-104 |
| E51L/T51L Motor Bracket |
Teflon Coated Cast Iron |
1-1810-0L-543 |
| Bronze |
1-1810-0L-206 |
| 316 Stainless |
1-1810-0L-104 |
| E51M/T51M Motor Bracket |
Teflon Coated Cast Iron |
1-1811-0M-543 |
| Bronze |
1-1811-0M-206 |
| 316 Stainless |
1-1811-0M-104 |
| E51P/T51P Motor Bracket |
Teflon Coated Cast Iron |
1-1812-0P-543 |
| Bronze |
1-1812-0P-206 |
| 316 Stainless |
1-1812-0P-104 |
| E51R/T51R Motor Bracket |
Teflon Coated Cast Iron |
1-3106-0R-543 |
| Bronze |
1-3106-0R-206 |
| 316 Stainless |
1-3106-0R-104 |
| 2 |
E51B/T51B Cover |
Teflon Coated Cast Iron |
2-1793-0B-543 |
| Bronze |
2-1793-0B-206 |
| 316 Stainless |
2-1793-0B-104 |
| E51C/T51C Cover |
Teflon Coated Cast Iron |
2-1794-0C-543 |
| Bronze |
2-1794-0C-206 |
| 316 Stainless |
2-1794-0C-104 |
| E51D/T51D Cover |
Teflon Coated Cast Iron |
2-1795-0D-543 |
| Bronze |
2-1795-0D-206 |
| 316 Stainless |
2-1795-0D-104 |
| E51E/T51E Cover |
Teflon Coated Cast Iron |
2-5039-0E-543 |
| Bronze |
2-5039-0E-206 |
| 316 Stainless |
2-5039-0E-104 |
| E51G/T51G Cover |
Teflon Coated Cast Iron |
2-1797-0G-543 |
| Bronze |
2-1797-0G-206 |
| 316 Stainless |
2-1797-0G-104 |
| E51J/T51J Cover |
Teflon Coated Cast Iron |
2-1798-0J-543 |
| Bronze |
2-1798-0J-206 |
| 316 Stainless |
2-1798-0J-104 |
| E51L/T51L Cover |
Teflon Coated Cast Iron |
2-1799-0L-543 |
| Bronze |
2-1799-0L-206 |
| 316 Stainless |
2-1799-0L-104 |
| E51M/T51M Cover |
Teflon Coated Cast Iron |
2-1800-0M-543 |
| Bronze |
2-1800-0M-206 |
| 316 Stainless |
2-1800-0M-104 |
| E51P/T51P Cover |
Teflon Coated Cast Iron |
2-1801-0P-543 |
| Bronze |
2-1801-0P-206 |
| 316 Stainless |
2-1801-0P-104 |
| E51R/T51R Cover |
Teflon Coated Cast Iron |
2-3105-0R-543 |
| Bronze |
2-3105-0R-206 |
| 316 Stainless |
2-3105-0R-104 |
| 4 |
Snap Ring |
18-8 Stainless |
4-2437-01-113 |
| 7 |
“O” Ring/Casing |
Buna |
7-1791-01-457 |
| Viton |
7-1791-01-494 |
| 7A |
“O” Ring/Drain
Plug |
Buna |
7-3970-01-457 |
| Viton |
7-3970-01-494 |
| 8 |
“O” Ring/Guide
Rod |
Buna |
8-1026-01-457 |
| Viton |
8-1026-01-494 |
| 11 |
E51B Impeller |
Bronze |
11-4915-0B-206 |
| W88 Stainless - ASTM A494 |
11-4915-0B-280 |
| Nickel/Silver Alloy - C97600 |
11-4915-0B-233 |
| T51B Impeller |
Bronze |
11-1780-0B-206 |
| Carbon Steel |
11-1780-0B-057 |
| W88 Stainless - ASTM A494 |
11-1780-0B-280 |
| E51C Impeller |
Bronze |
11-4916-0C-206 |
| W88 Stainless - ASTM A494 |
11-4916-0C-280 |
| Nickel/Silver Alloy - C97600 |
11-4916-0C-233 |
| T51C Impeller |
Bronze |
11-1781-0C-206 |
| Carbon Steel |
11-1781-0C-057 |
| W88 Stainless - ASTM A494 |
11-1781-0C-280 |
| E51D Impeller |
Bronze |
11-4917-0D-206 |
| W88 Stainless - ASTM A494 |
11-4917-0D-280 |
| Nickel/Silver Alloy - C97600 |
11-4917-0D-233 |
| T51D Impeller |
Bronze |
11-1782-0D-206 |
| Carbon Steel |
11-1782-0D-057 |
| W88 Stainless - ASTM A494 |
11-1782-0D-280 |
| E51E Impeller |
Bronze |
11-4918-0E-206 |
| W88 Stainless - ASTM A494 |
11-4918-0E-280 |
| Nickel/Silver Alloy - C97600 |
11-4918-0E-233 |
| T51E Impeller |
Bronze |
11-1783-0E-206 |
| Carbon Steel |
11-1783-0E-057 |
| W88 Stainless - ASTM A494 |
11-1783-0E-280 |
| E51G Impeller |
Bronze |
11-4919-0G-206 |
| W88 Stainless - ASTM A494 |
11-4919-0G-280 |
| Nickel/Silver Alloy - C97600 |
11-4919-0G-233 |
| T51G Impeller |
Bronze |
11-1784-0G-206 |
| Carbon Steel |
11-1784-0G-057 |
| W88 Stainless - ASTM A494 |
11-1784-0G-280 |
| E51J Impeller |
Bronze |
11-4920-0J-206 |
| W88 Stainless - ASTM A494 |
11-4920-0J-280 |
| Nickel/Silver Alloy - C97600 |
11-4920-0J-233 |
| T51J Impeller |
Bronze |
11-1785-0J-206 |
| Carbon Steel |
11-1785-0J-057 |
| W88 Stainless - ASTM A494 |
11-1785-0J-280 |
| E51L & E51M Impeller |
Bronze |
11-4921-LM-206 |
| W88 Stainless - ASTM A494 |
11-4921-LM-280 |
| Nickel/Silver Alloy - C97600 |
11-4921-LM-233 |
| T51L & T51M Impeller |
Bronze |
11-1786-LM-206 |
| Carbon Steel |
11-1786-LM-057 |
| W88 Stainless - ASTM A494 |
11-1786-LM-280 |
| E51P & E51R Impeller |
Bronze |
11-4922-0P-206 |
| W88 Stainless - ASTM A494 |
11-4922-0P-280 |
| Nickel/Silver Alloy - C97600 |
11-4922-0P-233 |
| T51P & T51R Impeller |
Bronze |
11-1787-0P-206 |
| Carbon Steel |
11-1787-0P-057 |
| W88 Stainless - ASTM A494 |
11-1787-0P-280 |
| 12 |
E51 Seal Rotating Element |
Buna/Carbon/316 SS |
Call factory for further assistance. |
| Viton/Carbon/316 SS |
| T51 Seal Rotating Element |
Buna/Carbon/316 SS |
| Viton/Carbon/316 SS |
| 125 |
E51 Seal Stationary Seat |
Ceramic |
125-4299-02-592 |
| Ni-resist |
125-4299-02-046 |
| T51 Seal Stationary Seat |
Ceramic |
125-1282-01-592 |
| Ni-resist |
125-1282-01-046 |
| 135 |
E51 Seal Seat Cup |
Buna |
135-1179-02-457 |
| Viton |
135-1179-02-494 |
| T51 Seal Seat Cup |
Buna |
135-1179-01-457 |
| Viton |
135-1179-01-494 |
| 14 |
Lock Collar/Sleeve |
Steel |
14-1049-01-080 |
| 15 |
Setscrew/Lock Collar |
316 Stainless |
15-1168-01-104 |
| 17 |
T51 Shaft Sleeve |
Bronze |
17-1390-01-181 |
| 316 Stainless |
17-1390-01-104 |
| 18 |
Guide Rod |
304 Stainless |
18-1099-01-104 |
| 19 |
Thru Bolt |
304 Stainless |
19-1997-01-080 |
| 20 |
Nut |
Steel |
20-1028-01-080 |
| 22 |
Plug/Drain - 1/8 SAE |
304 Stainless |
22-4265-01-101 |
| 23 |
Key/Impeller Drive |
316 Stainless |
23-1022-01-104 |
| 23A |
Key/Sleeve Drive |
Steel |
23-1487-01-080 |
