Models A3CR6M & 3CR6M to T31E Individual Curve

Back to Burks Replacements

Comparison

Burks Model Information

MTH Pumps Models information

Inlet / Discharge

Inlet / Discharge Tappings 1/2" NPT / 1/2" NPT 3/4" NPT / 3/4" NPT
Inlet / Discharge Orientation Side Inlet / Top Discharge Front Inlet / Top Discharge

Maximum Operating Conditions

Temperature (For Standard Buna-N Seal) 225°F (107°C) +230° F (+110° C)
Inlet Pressure 50 PSI (344kPa) 200 PSI (13.8 Bar)
Case Working Pressure 150 PSI (1034kPa) 300 PSI (20.6 Bar)
Viscosity 200 SSU (Approx. 46 CP) 250 SSU (Approx. 55 CP)

Available Materials of Construction

Casing / Motor Bracket Bronze Bronze
Impeller Bronze (Monel Blades) Bronze
Elastomers Buna-N Buna-N
Seal / Seal Seat Carbon / Ceramic Carbon / Ceramic
Shaft 316 SS 304 SS

Motor Configurations

Horsepower 1/3 1/3
Voltage

A3CR6M: 1-ph 115 Volt
3CR6M: 1-ph 230 Volt

T31:
Dual Voltage 1-ph 115/208-230 Volt
Dual Voltage 3-ph 208-230/460 Volt
Frame 36 48
Enclosure A3CR6M: non-Drip Proof
3CR6M: Open Drip Proof
1-ph: Open Drip Proof
3-ph: ODP or TEFC

Click and drag your mouse on the curve. Lines are automatically drawn as either horizontal or vertical. To clear the canvas, click the "Clear Lines" button below the curve.

Zoom

A3CR6M to T31E

Zoom

A3CR6M to T31E

Notes: --- --- --- Indicates altered performance at NPSH Available
*Horsepower data is valid for 1.0 specific gravity fluids only. Data provided is based of performance testing with water.
